Vòng bi quay ngược CKF-A45130; CKF-A80210; CK-B80140; CKZ A70180; CKZ A75181; CK-A55160; MG300; MG400; MG500; MG600; MG700; MI300; MI400; MI500; MI600; MI700; CKF-A2090; CKF-A2595; CKF-A30102; CKF-A35110; CKF-A40125; CKF-A45130; CKF-A50150; CKF-A55160; CKF-A60175; CKF-A70190; CKF-A80210; CKF-A90230; CKF-A100280; CKF-A130320; CKF-A150400; CKF25165; CKF30170; CKF35175; CKF40185; CKF55195; CKF55205; CKF60208; CKF65220; CKF70230; CKF80245; CKF90260; CKF100275; CKF110295; CKF130330; CKF140360; CKZ-A2080; CKZ-A35100; CKZ-A40115;CKZ-A40120; CKZ-A42125; CKZ-A45140; CKZ-A50150; CKZ-A55160; CKZ-A65170; CKZ-A70180; CKZ-A1890; CKZ-A2590; CKZ-A25100; CKZ-A28100; CKZ-A30100; CKZ-A32100; CKZ-A38115; CKZ-A45125; CKZ-A50135; CKZ-A5138; CKZ-A50160; CKZ-A50180; CKZ-A55145; CKZ-A55170
|
〔N-m〕 |
〔r/min〕 |
mm |
〔kg〕 |
|||||||||||
|
d(H7) |
D(h7) |
E(H7) |
F |
G |
C |
B |
A |
n-d1 |
bn×tn | |||||
|
CKF-A2090 |
140 |
875 |
6000 |
20 |
90 |
66 |
78 |
42 |
35 |
35 |
25 |
6-6.6 |
6×2.8 |
1.50 |
|
CKF-A2595 |
190 |
825 |
6000 |
25 |
95 |
70 |
82 |
46 |
35 |
35 |
25 |
6-6.6 |
8×3.3 |
1.60 |
|
CKF-A30102 |
340 |
780 |
6000 |
30 |
102 |
75 |
87 |
51 |
40 |
40 |
30 |
6-6.6 |
8×3.3 |
1.80 |
|
CKF-A35110 |
425 |
740 |
6000 |
35 |
110 |
82 |
96 |
58 |
40 |
40 |
30 |
6-6.6 |
10×3.3 |
2.10 |
|
CKF-A40125 |
625 |
720 |
5000 |
40 |
125 |
92 |
108 |
68 |
40 |
40 |
30 |
8-6.6 |
12×3.3 |
2.90 |
|
CKF-A45130 |
715 |
665 |
5000 |
45 |
130 |
94 |
112 |
70 |
40 |
40 |
30 |
8-9.0 |
14×3.8 |
3.10 |
|
CKF-A50150 |
1120 |
610 |
4000 |
50 |
150 |
114 |
132 |
90 |
40 |
40 |
30 |
8-9.0 |
14×3.8 |
4.70 |
|
CKF-A55160 |
1300 |
600 |
4000 |
55 |
160 |
116 |
138 |
86 |
45 |
45 |
34 |
8-9.0 |
16×4.3 |
5.40 |
|
CKF-A60175 |
1500 |
490 |
3200 |
60 |
175 |
135 |
155 |
95 |
70 |
60 |
47 |
8-11 |
18×4.4 |
8.50 |
|
CKF-A70190 |
2250 |
480 |
3200 |
70 |
190 |
140 |
165 |
100 |
70 |
60 |
47 |
12-11 |
20×4.9 |
10 |
|
CKF-A80210 |
3000 |
450 |
2400 |
80 |
210 |
160 |
185 |
120 |
80 |
70 |
48 |
12-11 |
22×5.4 |
14 |
|
CKF-A90230 |
4600 |
420 |
2400 |
90 |
230 |
180 |
206 |
140 |
90 |
80 |
67 |
12-13.5 |
25×5.4 |
19 |
|
CKF-A100280 |
7600 |
455 |
2000 |
100 |
280 |
200 |
240 |
160 |
105 |
100 |
67 |
12-17.5 |
28×6.4 |
34 |
|
CKF-A130320 |
13600 |
415 |
2000 |
130 |
320 |
235 |
278 |
195 |
105 |
100 |
67 |
12-17.5 |
32×7.4 |
44 |
|
CKF-A150400 |
24500 |
365 |
2000 |
150 |
400 |
320 |
360 |
256 |
105 |
100 |
86 |
12-17.5 |
36×8.4 |
73 |
